CRBS508CRBS608CRBS708CRBS808CRBS908CRBS1008CRBS1108CRBS1208CRBS1308CRBS1408
| 軸徑 | 型號 | 主要尺寸 | 基本額定載荷 | CRBS 帶保持架 |
CRBS…AUU 帶隔離塊 |
CRBS…V CRBS…VUU 滿裝 |
重量 | ||||||||||
| 帶保持架開式 | 帶隔離塊密封 | 滿裝滾子 | d | D | B | rs | Cr | Cor | 基本額定動載荷 | 基本額定靜載荷 | 基本額定動載荷 | 基本額定靜載荷 | 基本額定動載荷 | 基本額定靜載荷 | Kg | ||
| 開式 | 密封 | C | Co | C | Co | C | Co | ||||||||||
| mm | mm | mm | min | KN | KN | KN | KN | KN | KN | KN | KN | ||||||
| 50 | CRBS508 | CRBS508AUU | CRBS508V | CRBS508VUU | 50 | 66 | 8 | 0.4 | 4.9 | 6.17 | 4.9 | 6.17 | 4.68 | 5.81 | 6.93 | 9.8 | 0.084 |
| 60 | CRBS608 | CRBS608AUU | CRBS608V | CRBS608VUU | 60 | 76 | 8 | 0.4 | 5.35 | 7.31 | 5.35 | 7.31 | 5.35 | 7.31 | 7.6 | 11.7 | 0.094 |
| 70 | CRBS708 | CRBS708AUU | CRBS708V | CRBS708VUU | 70 | 86 | 8 | 0.4 | 5.74 | 8.44 | 5.74 | 8.44 | 5.74 | 8.44 | 8.19 | 13.6 | 0.108 |
| 80 | CRBS808 | CRBS808AUU | CRBS808V | CRBS808VUU | 80 | 96 | 8 | 0.4 | 6.13 | 9.59 | 6.13 | 9.59 | 6.13 | 9.59 | 8.79 | 15.5 | 0.122 |
| 90 | CRBS908 | CRBS908AUU | CRBS908V | CRBS908VUU | 90 | 106 | 8 | 0.4 | 6.49 | 10.7 | 6.49 | 10.7 | 6.49 | 10.7 | 9.31 | 17.4 | 0.135 |
| 100 | CRBS1008 | CRBS1008AUU | CRBS1008V | CRBS1008VUU | 100 | 116 | 8 | 0.4 | 6.85 | 11.9 | 6.85 | 11.9 | 6.53 | 11.1 | 9.85 | 19.3 | 0.152 |
| 110 | CRBS1108 | CRBS1108AUU | CRBS1108V | CRBS1108VUU | 110 | 126 | 8 | 0.4 | 7.16 | 13 | 7.16 | 13 | 6.85 | 12.3 | 10.3 | 21.2 | 0.163 |
| 120 | CRBS1208 | CRBS1208AUU | CRBS1208V | CRBS1208VUU | 120 | 136 | 8 | 0.4 | 7.53 | 14.1 | 7.53 | 14.1 | 7.07 | 13 | 10.9 | 23 | 0.184 |
| 130 | CRBS1308 | CRBS1308AUU | CRBS1308V | CRBS1308VUU | 130 | 146 | 8 | 0.4 | 7.86 | 15.3 | 7.86 | 15.3 | 7.27 | 13.8 | 11.2 | 24.6 | 0.199 |
| 140 | CRBS1408 | CRBS1408AUU | CRBS1408V | CRBS1408VUU | 140 | 156 | 8 | 0.4 | 8.06 | 16.4 | 8.06 | 16.4 | 7.51 | 14.9 | 11.7 | 26.8 | 0.205 |
| 150 | CRBS1508 | CRBS1508AUU | CRBS1508V | CRBS1508VUU | 150 | 166 | 8 | 0.4 | 8.35 | 17.5 | 8.35 | 17.5 | 7.81 | 16 | 12.1 | 28.7 | 0.22 |
| 160 | CRBS16013 | CRBS16013AUU | CRBS16013V | CRBS16013VUU | 160 | 186 | 13 | 0.6 | 20.3 | 39.9 | 20.3 | 39.9 | 19.4 | 37.7 | 26.9 | 58.2 | 0.62 |
| 170 | CRBS17013 | CRBS17013AUU | CRBS17013V | CRBS17013VUU | 170 | 196 | 13 | 0.6 | 20.9 | 42.2 | 20.9 | 42.2 | 20 | 39.9 | 27.8 | 61.6 | 0.675 |
| 180 | CRBS18013 | CRBS18013AUU | CRBS18013V | CRBS18013VUU | 180 | 206 | 13 | 0.6 | 21.5 | 44.6 | 21.5 | 44.6 | 21.9 | 45.7 | 28.6 | 65.2 | 0.71 |
| 190 | CRBS19013 | CRBS19013AUU | CRBS19013V | CRBS19013VUU | 190 | 216 | 13 | 0.6 | 22.1 | 46.9 | 22.1 | 46.9 | 22.9 | 49.2 | 29.3 | 68.6 | 0.74 |
| 200 | CRBS20013 | CRBS20013AUU | CRBS20013V | CRBS20013VUU | 200 | 226 | 13 | 0.6 | 22.5 | 49.3 | 22.5 | 49.3 | 23.3 | 51.6 | 30 | 72.2 | 0.78 |
